207589 207589 207589 Motorola
Motorola Data Terminal Motorola Data Terminal Motorola Data Terminal Motorola Data Terminal Motorola Data Terminal Motorola Data Terminal

Motorola Data Terminal
Part #: VC70N0-AC-U-R | SKU: MOT207589

The Motorola VC70N0 Fixed Mount Vehicle Terminal is the right sized mobile computer that is needed to improve productivity and task accuracy in any conditions. The VC70N0 supports applications, covering receiving, put-away, replenishment, picking, packing, and shipping. A wide range of options available to maximize efficiency with corded or cordless barcode scanners, keyboards, and a variety of voice capabilities.

Motorola Data Terminal

Part Details: Zebra VC70N0 Ultra-Rugged Vehicle-Mounted Mobile Computer - Texas Instruments 1 GHz - 512 MB RAM - 2 GB Flash Memory - 10.4" LCD - XGA - 1024 x 768 - Wi-Fi - IEEE 802.11a/b/g/n - Serial - USB - Windows Embedded Compact 7
InStock
Need a different version of the Motorola VC70N0 Data Terminal? View all 5 configurations

Additional Information

Display Size 10.4"
Form Factor Fixed
Interface Options Wi-Fi.
Internal Storage 2GB Flash
Keyboard Touch-based
Manufacturer AIDC Motorola
Model Name VC70N0
Operating System Windows CE 7.0
Motorola VC70N0 Specs Motorola VC70N0 Specs (pdf)

General Information

  • Product Type: Vehicle Mount Terminal
  • Brand Name: Motorola
  • Manufacturer: Motorola, Inc
  • Product Model: VC70N0
  • Product Name: VC70N0 Ultra-Rugged Vehicle-Mounted Mobile Computer

Technical Information

  • Connectivity Technology: Wireless

Physical Characteristics

  • Width: 8.9"
  • Depth: 2.4"
  • Length: 11.5"

Interfaces/Ports

  • Interfaces/Ports:
    • 2 x RS-232 Serial
    • 3 x USB
    • 1 x CANbus
    • 1 x RJ-45 Network

Other

  • Green Compliant: Yes
  • Green Compliance Certificate/Authority:
    • RoHS
    • WEEE
  • Certifications & Standards:
    • IP 66
    • MIL -STD 810G; Method 514.6
    • MIL -STD 810G; Method 516.6
    • MIL -STD 810G
    • IEC 68-2-5
    • Electrical Safety:
    • UL /cUL /IE C/EN 60950-1 Indoor Use
    • UL /cUL /IE C/EN 60950-22 Outdoor Use
    • EMI /RFI:
    • FCC Part 15, Class B
    • ICES 003 Class B
    • EN55022
    • EN 301 489-1
    • EN 301 489-17
    • WLAN:
    • FCC Part 15.247, 15.407
    • RSS-210
    • EN 300 328
    • EN 301 893
    • AS/NZS 4268
    • Flammability:
    • IEC UL 94-VO

Display & Graphics

  • Touchscreen: Yes
  • Display Screen Type: LCD
  • Screen Size: 10.4"
  • Graphics Modes: XGA
  • Display Resolution: 1024 x 768

Environmental Conditions

  • Electrostatic Discharge (ESD):
    • +/-15 kV DC Air Discharge
    • +/-8 kV DC Direct Discharge

Processor & Chipset

  • Processor Manufacturer: Texas Instruments
  • Processor Speed: 1 GHz

Memory

  • Flash Memory: 2 GB
  • Standard Memory: 512 MB

Network & Communication

  • Wireless LAN Standard: IEEE 802.11a/b/g/n
  • Wireless Technology: Wi-Fi

Warranty

  • Limited Warranty: 1 Year

Software

  • Operating System: Windows Embedded Compact 7
Extended Details

Recommended Accessories for Model: Motorola Data Terminal

  • Zebra Power Device
    Part #: 23844-00-00R | SKU: ZEB26223

    US AC Line Cord, Grounded, 7.5', Three wire for power supplies.
    Price: $20.56
    In Stock

  • Zebra Power Device
    Part #: 50-16000-221R | SKU: ZEB26272

    Power Device - Zebra - AC Line Cord - Grounded - 6 Feet Or 1.8 Meters - 3-Prong - USA Nema 5-15P Plug - Associated Countries - Canada - Mexico - United States.
    $26.47
    See Price in Cart (Why?)
    In Stock

  • Zebra Power Device
    Part #: 50-16000-678R | SKU: ZEB46517

    MC67 Accessories, AC Line Cord, 36"L grounded, three wire. Associated Countries: Brazil, United States. For power supplies KT-14000-148R and 50-14000-241R.
    Price: $20.56
    See Price in Cart (Why?)
    In Stock

  • Zebra Power Device
    Part #: PWRS-9-60VDC-01R | SKU: ZEB207599

    VC70N0 Accessories, External DC Power supply, VC70, 9-60VDC Requires (Part# 25-159551-01) fused DC power cable to vehicle battery
    $939.83
    See Price in Cart (Why?)
    In Stock

  • Zebra Battery
    Part #: BTRY-VC70IAB00 | SKU: ZEB216861

    SPARE BATTERY;VC70
    $155.58
    See Price in Cart (Why?)
    In Stock
