2-D Imager Engine
Illumination element (LED)
625 +/- 5 nm LEDs (2x)
Aiming element (VLD)
655 +/- 10 nm Laser
Field of View
Horizontal: 40Ā°; Vertical: 25Ā°
Ranges
From center of exit window: SR ā 7.5 in./19 cm
Pitch angle
+/-60Ā°
Roll
360Ā°
Skew tolerance
+/-60Ā°
Sensor resolution
752 x 480 pixels
Communications
GPS
Integrated standalone or Assisted-GPS (A-GPS); SiRFstarIII GSC3f/LP
chipset
WWAN
MC9500: Modular 3.5G WAN (GSM HSDPA or CDMA-EVDO Rev A); MC959B:
Modular 3.5G Dual-WAN (GSM HSUPA and CDMA EVDO Rev A)
WPAN (Bluetooth Support)
Bluetooth 2.1 with EDR, IrDA
WLAN
Tri-mode IEEE 802.11a/b/g ;CCXv4 certified; Support for IPv6;
FIPS140-2 Certified
Security
WPA2 (Personal or Enterprise); 802.1x; EAP-TLS;
TTLS (CHAP, MS-CHAP, MS-CHAPv2, PAP or MD5); PEAP (TLS, MSCHAPv2,
EAP-GTC); LEAP,
EAP-FAST (TLS, MS-CHAPv2, EAP-GTC); CCXv4 certified; support for
IPv6; FIPS 140-2 Certified
Linear 1-D Scanner
Scan angle
47Ā° +/- 3Ā° default; 35Ā° +/- 3Ā° reduced
Scan rate
104 (+/- 12) scans/sec (bi-directional)
Optical resolution
4 Mil minimum element width
Notices and Disclaimers
See footnote.1
Performance Characteristics
Processor (CPU)
Marvell PXA320 @ 806 MHz
Operating system (OS)
MC9500: Microsoft Windows Mobile 6.5 Professional, Microsoft
Windows Mobile 6.5 Classic Edition; MC959B: Microsoft Windows
Mobile 6.1
Memory (Flash/RAM)
256MB RAM/1GB Flash
Data capture options
1-D laser scanner or 2-D imager and 3 megapixel auto focus color
camera
Physical Characteristics
Dimensions (HxWxD)
9.2 in. H x 3.5 in. W x 2 in. D/23.36 cm H x 8.89 cm W x 5.08 cm
D
Weight
22 oz./623 g (with battery, stylus, keypad and strap)
Display type
3.7 in. color (TFT) with digitizer and backlight
Display resolution
VGA (640 x 480)
Audio options
Bluetooth, VOWWAN, VOWLAN, TEAM Express compliant, Rugged audio
connector, Handset and headset modes, Speakerphone
Keypad options
Modular: Alpha Primary; Numeric Telephony, Numeric Calculator,
Alpha Numeric
Notification
Vibrator, Audio notifications, Programmable LEDs
Expansion slot
microSD - supports up to 16GB
Zebra Interactive Sensor Technology (ISTT)
3-axis accelerometer that enables motion-sensing applications on
dynamic screen orientation, power management and free-fall
detects
Headset
Bluetooth headset, Wired headset
Power
Battery
PowerPrecision Lithium Ion battery 4800 mAh with State of Charge
and State of Health indicators
Regulatory Specifications
Hazardous location certifications
UL Class I, II, III Division II, A, B, C, D, F, G (Select
Configurations Only)
Electrical safety
UL 60950-1, CSA C22.2 No. 60950-1, EN 60950-1, IEC 60950-1
Environmental
RoHS-compliant
Laser safety2
EN 60825-1, IEC Class 2/FDA Class II, IEC 60825-1 Class 2
EMI/RFI
USA: FCC Part 15, Class B; Canada: ICES-003 Class B; EU: EN55022
Class B, EN 55024, EN 301 489-1, EN 301 489-7, EN 301 489-17, EN
301 489-19, EN 301 489-24, EN 60601-1-2, EN 50121-3-2, EN
50121-4
RF exposure
USA: FCC Part 2, FCC OET Bulletin 65 Supplement C;Canada: RSS-102;
EU: EN 50360; Japan: ARIB STD T56; Australia: Radiocommunications
Standard 2003
User Environment
Ambient lighting tolerance3
Tolerant to typical artificial indoor and natural outdoor (direct
sunlight) lighting conditions. Fluorescent, Incandescent, Mercury
Vapor, Sodium Vapor, LED : 450 Ft Candles (4,844 Lux) Sunlight:
8000 Ft Candles (86,111 Lux)
SAP certification4
See footnote.
Drop specification
Multiple 6 ft./1.8 m drops to concrete across the operating
temperature range;Meets and exceeds MIL-STD 810G
Operating temperature
-4Ā° to 122Ā° F/-20Ā° to 50Ā° C
Storage temperature
Ambient to -40Ā°F/-40Ā°C; Ambient to 158FĀ° /70Ā°C
Humidity
5-95% non-condensing
Environmental sealing
IP67; meets or exceeds applicable IEC sealing specifications
Tumble specifications
2000 3.2 ft./1 m tumbles (4,000 hits) at room temperature; meets
and exceeds applicable IEC tumble specifications
Electrostatic discharge (ESD)
+/-15kv Air discharge; +/-8kv direct discharge; +/- 8kv indirect
discharge
