Xerafy RFID Tag
Part #: X4202-US100-U9XM | SKU: XER797195

XERAFY XS WEDGE is an exceptional choice for industries that demand robust asset tracking under difficult conditions. Designed with a compact and resilient structure, this RFID tag is engineered to endure extreme temperatures and harsh chemicals, making it highly suitable for automotive manufacturing, heavy machinery, and offshore activities. With its reliable performance when embedded in metal, the XS WEDGE features a lifetime chip data retention of up to 50 years, guaranteeing long-lasting efficiency in your inventory management processes.

Key Features

• Embeddable: Can be embedded with ease into metal surfaces.
• High Temperature Resistance: Capable of withstanding temperatures up to 250°C.
• Compact Size: Small form factor, ideal for assets requiring minimal space.
• Durability: Injection molded case that resists liquids, pressure, and corrosion.

Specifications

• Technical Specifications:
  • RF Protocol: EPC global Class 1 Gen 2
  • Frequency: 902-928 MHz (US); 865-868 MHz (EU)
  • Chip Type: Alien Higgs 9
  • Chip Memory: 96 bits EPC, 96 bits TID, 688 bits user memory
  • Read Range (Fixed): Up to 3.28 ft (1 m) US; Up to 1.97 ft (0.60 m) EU
  • Read Range (Handheld): Up to 1.64 ft (0.50 m) US; Up to 1.31 ft (0.40 m) EU
  • Polarization: Linear
• Environmental Specifications:
  • Operational Temperature: -40°C to +85°C
  • Survival Temperature: -50°C to +220°C (168 hours)
  • Peak Temperature: 250°C (2 hours)
  • IP Rating: IP68
  • Compression Strength: 10,100 psi (70 MPa)
• Physical Specifications:
  • Material: Industry grade polymer
  • Dimensions: Ø 10.30 mm x 4.60 mm
  • Weight: 0.28 oz (8 g)
• Order Information:
  • XS Wedge US: X4202-US100-H9
  • XS Wedge EU: X4202-EU100-H9
