RJS Barcode Verifier

The Model D4000 Provides the Two Most Popular Types of Verification: ANSI Method and-or Point-and-Shoot Traditional Method. This unique portable barcode verifier can interface with either the patented RJS Auto-Optic scan head or a laser scanner to provide nine different optic configurations. The scanners are easily installed by the user making the unit quickly adaptable to practically any verification requirement. A D4000 incorporating an Auto-Optic scanner is the industry's most flexible ANSI method verifier. Eight optical arrangements are possible via menu selections for four aperture sizes and two wavelengths of light. The optical geometry meets all requirements of the ANSI X3.182 Barcode Quality Guideline. The Auto-Optic scanner is designed and manufactured by RJS for the sole purpose of performing ANSI method barcode quality analysis. Repeatability between units is outstanding making the D4000 an ideal choice as a standardized company-wide ANSI method verifier. A D4000 incorporating a laser scanner is an extremely easy to use point-and-shoot verifier. It requires virtually no user training and analyzes most of the essential traditional verification parameters. It also provides the ANSI method Decodability calculation and percent of decode information. Popular applications include verification on materials requiring special considerations such as shiny curved or uneven surfaces and wet ink.

The TP 140 is recommended if the Scan Reflectance Profile graphics portion of the printout from an ANSI method verifier is required. RJS ANSI method verifier models compatible with the TP140 are Inspector D4000 w-Auto-Optic Inspector 4000 and Inspector 3000.

Inspector D4000, Combo (3,6,10,20 mil and Laser) - North America. Ideal for high volume production environment when FULL ISO/ANSI AND PARTIAL spot testing barcode quality testing in North America.

Inspector 5000, Laser (Laser)

Form Printer - RJS TP140B - USB Cable - 110 VAC

Inspector D4000 Series Accessories, Inspector D4000 CR2 Laser Scanner, D4000/L1000. NOT entire barcode verifier. Replacement part or add-on only which REQUIRES customer already has (Part# 002-7850) or (Part# 002-7851) or (Part# 002-7845).

Paper TP140A, 2 rolls (574 feet)
