Motorola HC1 Mobile Computer

Imagine instantly accessing and viewing business critical documents and complex schematics with just a simple voice command or turn of your head; or to quickly and simply collaborate with remote team members. No hands, laptop or fixed mobile workstation required. That’s the power of the HC1 Headset Computer from Motorola Solutions. This exciting new class of mobile computing device delivers true hands-free capabilities to a wide variety of industries. With HC1, users can be more productive at the point of activity, work more efficiently and safely — whether they’re in a tight space, in a remote location or working high above the ground

See all options

Specs & Info
All Options

Motorola HC1 Specs (pdf)

Communications

Supported profiles
Discovery & Connect, HID, COM (SPP), BT PAN-Adhoc, BT PAN-AP, Handsfree, OBEX FTP, PBAB

Security
WLAN Security: WPA, WPA2, WEP

WPAN (Bluetooth Support)
Bluetooth 2.1 with EDR

WLAN
802.11b/g

Performance Characteristics

Processor (CPU)
Texas Instruments OMAP 3730 Series Dual Core Processor, 800 MHz, 3D Graphic Accelerator

Operating system (OS)
Microsoft Windows CE 6.0 Pro

Memory
512MB RAM and 512MB Flash

Voice recognition
98-99% accuracy, natural language software (no learning required), supports 6 languages (English, French, Italian, German, Spanish, Portuguese)

Physical Characteristics

Dimensions (HxWxD)
Designed to fit a wide range of users, from 5th percentile female to a 95th percentile male head size.

Weight
With standard battery (camera module not included): 22.9oz./650g
With extended life battery (camera module not included): 26.5oz./750g
Camera module: 3.70oz./105g

Noise cancellation
Active, ambient noise-cancellation (dual microphone)

User programmable buttons
Two

Expansion slot
User accessible microSD card slot (support for up to 32GB)

Audio options
User removable Near-Ear Loudspeaker Module; built-in dual microphones

Notification
LED (Suspend and Battery Charge Status)

Gesture control
9-axis tracking and gesture mobile (accelerometer, gyroscope and digital compass)

Display type
Full color, SVGA, Transmissive TFT (800 x 600) micro-display with an adjustable backlight; Field of view: 32 degrees (diagonal); Virtual image size: 15 in. diagonal

Power

Battery
Standard Battery: Rechargeable Lithium Ion 3.7V, 1950mAh
Extended Life Battery: Rechargeable Lithium Ion 3.7V, 4800mAh

Regulatory Specifications

RF exposure
FCC Parts 15.247, 15.205, 15.207, 15.209, 15.203, EN 300 328, RSS-210

EMC
ICES 003 Class B, EN 61000-3-2, EN 61000-3-3, EN 60601-1-2, CISPR 22 Class B, CISPR 24, FCC Part 15 Subpart B

Electrical safety
CSA C22.2 No. 60950-1, Certified to UL60950-1, EN60950/IEC 60950-1 plus all national deviations

User Environment

Environmental sealing
IP65

Electrostatic discharge (ESD)
±15kV air discharge, ±8kV contact discharge (Relative Humidity 50%)

Humidity
5% to 95% non-condensing

Tumble specifications
500 tumbles (1000 hits) @ 1.64 ft./0.5m

Drop specification
4 ft./1.2m to concrete across operating temperature per MIL-STD-810

Shock/Vibration
2Gs peak, 5Hz to 2kHz, 1 hour duration per axis

Storage temperature
-40° to 158° F/-40° to 70° C

Operating temperature
14° to 122° F/-10° to 50° C

Extended Details

Refine Your Options

Motorola Mobile Computer
Part #: HC170-D0A1Y210WR | SKU: MOT232036

HC1 Headset Computer, (802.11b/g, Bluetooth, Display, CE6P, 512/512, EXT Battery)
