Industrial Bar code Scanner

Powerful and compact, the new Gryphon GFS4400 scan module packs all the first class features of Gryphon premium 2D bar code readers in a small package, providing the ideal solution for hands-free reading and use in semi-automatic equipment. Designed with system integration in mind, its optimum motion tolerance allows fast processing in automated applications and its great depth of field makes reading easy and intuitive. Plus, the Gryphon GFS4400 scan module’s small size and outstanding near-field reading are ideal for incorporation in the confined spaces required by semi-automatic equipment.

The Datalogic Gryphon GFS4100 reader is a state-of-the-art linear imager. It is capable of reading high resolution bar codes up 3 mils. It has outstanding performance on poorly printed or damaged bar codes and a long reading range compared to other scanners in its class. On standard EAN13 or UPC 13 mil bar codes, the Gryphon GFS4100 scanner reads from 3.0 cm / 1.2 in to over 40.0 cm / 15.7 in at extreme skew angles with no degradation of the reading speed. Imagers like the Gryphon GFS4100 can capture data as fast as 320 frames per second, compared to 100 frames per second in laser scanners. Faster processors analyze the data using a sophisticated library of solutions, developed and refined over decades of experience in the industry. This makes Datalogic's imaging scanners the best solution for speed, accuracy and reliability.

The Datalogic CBX Series are industrial connection boxes designed to speed up installation, configuration and maintenance tasks of Datalogic Automation’s 1D/2D code readers. The complete range of optional modules provides connectivity to the most common fieldbus systems while extending communication capabilities.

Enhance your kiosk with high performance, versatile data capture. One of the smallest charged couple device (CCD) imaging products available today, the Symbol MS4400 1D and 2D barcode scanning, image capture and direct part mark (DPM) reading wherever a small footprint is required. From the check-in kiosk to point of sale (POS) areas with limited counter space or even integrated within clinical diagnostic equipment, the Symbol MS4400 delivers a new level of miniaturization. With built-in features like omnidirectional scanning and intuitive aiming, the Symbol MS4400 ensures fast, accurate scanning, regardless of who is scanning or capturing images your employees or your customers.

Enhance your kiosk with high performance, versatile data capture. One of the smallest charged couple device (CCD) imaging products available today, the Symbol MS4400 1D and 2D barcode scanning, image capture and direct part mark (DPM) reading wherever a small footprint is required. From the check-in kiosk to point of sale (POS) areas with limited counter space or even integrated within clinical diagnostic equipment, the Symbol MS4400 delivers a new level of miniaturization. With built-in features like omnidirectional scanning and intuitive aiming, the Symbol MS4400 ensures fast, accurate scanning, regardless of who is scanning or capturing images your employees or your customers.

The Symbol MiniScan MS1204 Barcode Reader is a compact, durable, industrial fixed mount scanner available in fuzzy (FZY) version for maximum versatility. The MiniScan MS1204 Barcode Reader features fuzzy logic for premium scanning on 1D barcodes including poorly printed and low contrast. The Symbol MiniScan MS1204 is an excellent choice for OEM devices requiring accurate, automated data collection, even in the most demanding environments. It can also be used as a standalone fixed mount scanner.

The Datalogic Matrix 210 is a 2D reader offering extreme reading performance and integrated Ethernet in a ultra-compact housing. Thanks to the WVGA image sensor, capturing up to 60 frames per second and to the powerful internal illuminator, the Matrix 210 offers extreme dynamic reading capability. The unrivaled decoding libraries running on the high speed hardware platform deliver superior reading robustness and impressive decoding rates, supporting high system throughput and so improving efficiency of productions. The on-board Ethernet makes effective the transfer of both reading data and captured images, that can be easily and quickly uploaded on external PCs or servers, simply for storage or also for offline process analysis.

The Datalogic DS4800 is an industrial laser scanner combining flexibility and compactness thus satisfing all application needs of the production plant. Through the smart focus adjustment the DS4800 optimizes the performances based on the reading distance. This extends the reading area and improves the overall read rate. Thanks to DIGITECH technology, the DS4800 provides excellent reading performance on low quality barcodes. By means of optimized reading recipes, DS4800 improves reading rate on low contrast barcodes while granting excellent performance at high skew angles. Additionally, ACR4 reconstruction technology increases the max tilt angle and decoding rate on damaged barcodes.

The Microscan Mini Hawk consistently reads damaged, distorted or otherwise challenging direct part marks with our patented decode algorithms. For real time dynamic autofocus, position the symbol at the center of the field of view, and push the EZ button. The MINI Hawk automatically adjusts focal distance and sets internal parameters to optimize the symbol.

The MS-3 Laser is designed for embedded applications, the MS-3 Laser laser series meets demanding space and budget requirements while offering an exceptional feature-set. The MS-3 Laser series provides exceptional versatility in size and functionality.
