Altronix Power Device

Model 6062 programmable timer is suitable for many functions that require a timed operation e.g. Access Control Applications, Siren/Bell Cut Off Module, Dialer Delay, Guard Tour Supervisory Timer, etc. Some optional functions include: One Shot, Delayed Release, Delayed Operate, Delayed Pulse and Pulser/Flasher. A new feature has been added which provides a momentary relay activation at the end of a desired timing cycle. This feature eliminates the need for having to use two (2) timers to achieve this function. Another new feature will cancel (interrupt) timing cycle and reset timer if desired.

ACM8E unit converts one (1) 12 to 24 volt AC or DC input into eight (8) independently controlled fuse protected outputs. These power outputs can be converted to dry form C contacts. Outputs are activated by an open collector sink or normally open (NO) dry trigger input from an Access Control System, Card Reader, Keypad, Push Button, PIR, etc. The unit will route power to a variety of access control hardware devices including Mag Locks, Electric Strikes, Magnetic Door Holders, etc. Outputs will operate in both Fail-Safe and/or Fail-Secure modes. The unit is designed to be powered by one common power source which will provide power for both the board operation and locking devices, or two (2) totally independent power sources, one (1) providing power for board operation and the other for lock / accessory power. The FACP Interface enables Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary devices. The fire alarm disconnect feature is individually selectable for any or all of the eight (8) outputs.

Model AL1012ULACM converts a 115 VAC 60Hz input into eight (8) independently controlled 12VDC non power limited fuse protected Fail-Safe and/or Fail-Secure outputs with a total of 10 amp continuous supply current. The fire alarm disconnect feature enables emergency egress in the event the fire alarm system is activated. It is individually selectable for any or all of the eight (8) outputs.

Model AL1024ULACM converts a 115 VAC 60Hz input into eight (8) independently controlled 24VDC non power limited fuse protected Fail-Safe and/or Fail-Secure outputs with a total of 10 amp continuous supply current. The fire alarm disconnect feature enables emergency egress in the event the fire alarm system is activated. It is individually selectable for any or all of the eight (8) outputs.

Model AL125UL power supply converts a 115 VAC 60Hz input, to a 12VDC or 24VDC at 1 amp of total supply current Class 2 Rated power limited output.

Model AL175ULX power supply converts 115 VAC 60Hz input, into two (2) PTC protected 12VDC or 24VDC at 1.75 amp Class 2 Rated power limited supply current outputs.

Model AL400ULACM converts a 115 VAC 60Hz input into eight (8) independently controlled non power limited fuse protected Fail-Safe and/or Fail-Secure outputs with a total of 12VDC at 4 amp or 24VDC at 3 amp of continuous supply current. The fire alarm disconnect feature enables emergency egress in the event the fire alarm system is activated. It is individually selectable for any or all of the eight (8) outputs. Model AL400ULACMCB is a PTC protected version of this unit.

Model AL400ULM is specifically designed for use with access control systems and accessories. This unit converts a 115 VAC 60Hz input into five (5) PTC protected 12VDC at amp or 24VDC at 3 amp Class 2 Rated power limited outputs. Model AL400ULMR is a Red Cabinet version of this product.

Model AL600ULM is specifically designed for use with access control systems and accessories. This unit converts a 115 VAC 60Hz input into five (5) PTC protected 12VDC or 24VDC at 6 amp Class 2 Rated power limited outputs.
